全自動晾茬機是一種新型釀酒設備，具有速度快，效率高等特點?？勺詣?dòng)加水、下曲、出料、攪拌均勻、散冷效果及其理想。下面來介紹下全自動涼茬機的結構組成及機架相關內容。
Automatic stubble drying machine is a new type of brewing equipment, which has the characteristics of high speed and high efficiency. It can automatically add water, bend, discharge, stir evenly, and have ideal cooling effect. Next, we will introduce the structure of the automatic stubble cooler and the related contents of the rack.
全自動涼茬機的結構組成
Structure of automatic stubble cooler
1.主要由機架、風機、傳送帶和依次連接于傳送帶上的攪籠、打料棍、翻料棍、下料裝置、出料管組成.
1. It is mainly composed of a frame, a fan, a conveyor belt and a stirring cage, a beating stick, a turning stick, a blanking device and a discharge pipe connected to the conveyor belt in turn
2.風機固定在傳送帶側端的機架上并少設置為三臺，所述的下料裝置由下料斗和固接于下料斗下部的下料輥組成，所述的機架上設有高于傳送帶輸送線兩邊的擋板。
2. The fan is fixed on the frame at the side end of the conveyor belt and is set with at least three sets. The blanking device is composed of a blanking hopper and a blanking roller fixed at the lower part of the hopper. The frame is provided with baffles higher than both sides of the conveyor line of the conveyor belt.
3.使用時，酒茬在傳送帶上通過，在打碎和攪拌的同時風機工作，迅速降溫，冷卻后的酒茬在下料裝置中與酒曲自動混合均勻。
3. When in use, the wine stubble passes through the conveyor belt. While crushing and mixing, the fan works to quickly cool down. The cooled wine stubble is automatically mixed with koji in the blanking device.
4.全自動打茬機提升了冷卻效果、降低了功耗，了現有設備自積堵塞現象，并實現了酒茬和酒曲的自動混合。
4. The full-automatic stubble cutting machine improves the cooling effect, reduces power consumption, solves the self accumulation blockage of existing equipment, and realizes the automatic mixing of wine stubble and distiller's yeast.
全自動晾茬機機架
Relevant introduction of the frame of automatic stubble drying machine
全自動晾茬機的特征是：由機架、風機、傳送帶和依次連接于傳送帶上的攪籠、打料輥、翻料輥、下料裝置、出料管組成，風機固定在傳送帶側端的機架上并少設置為三臺，下料裝置由下料斗和固接于下料斗下部的下料輥組成，機架上設有高于傳送帶輸送線兩邊的擋板。
The full-automatic stubble drying machine is characterized by: it is composed of a frame, a fan, a conveyor belt and a stirring cage, a beating roller, a turnover roller, a blanking device and a discharge pipe connected to the conveyor belt in turn. The fan is fixed on the frame at the side end of the conveyor belt and is set with at least three sets. The blanking device is composed of a lower hopper and a blanking roller fixed at the lower part of the lower hopper. The frame is equipped with baffles higher than both sides of the conveyor line of the conveyor belt.
全自動晾茬機包括機架，機架的上料端與加料結構連接、出料端與出料結構連接，上料端設有一帶輪，出料端設有二帶輪，一帶輪與二帶輪通過輸送帶連接，二帶輪通過減速機與驅動電機連接，驅動電機與機架連接，二帶輪位置高于一帶輪位置。
The full-automatic stubble drying machine includes a frame. The feeding end of the frame is connected with the feeding structure, and the discharging end is connected with the discharging structure. The feeding end is equipped with a belt wheel, and the discharging end is equipped with two belt wheels. The belt wheel is connected with the two belt wheels through the conveyor belt, and the two belt wheels are connected with the drive motor through the reducer. The drive motor is connected with the frame, and the position of the two belt wheels is higher than the position of the belt wheel.
每臺晾茬機都有接曲裝置組成，接曲裝置是晾茬機比較重要的裝置之一。接曲裝置位于晾茬機的底部，形成對下料口漏料的收集作用，從而節約物料，避免出現浪費的現象。更多相關內容就來網站
http://www.xgbmw.cn咨詢了解吧！
Each stubble airing machine is composed of a bending device, which is one of the more important devices of stubble airing machine. The bending device is located at the bottom of the stubble drying machine to collect the leaked materials at the blanking port, so as to save materials and avoid waste. Come to the website for more relevant content http://www.xgbmw.cn Consult and understand!
