全自動涼茬機是一種新型的釀造設備，具有速度快、效率高的特點?？勺詣蛹铀?、彎管、卸料、攪拌均勻，冷卻效果理想。彎曲裝置是冷茬機中比較重要的裝置之一。彎管裝置位于冷茬機底部，對出料口漏出的物料形成收集作用，從而節省材料，避免浪費。
Automatic stubble cooler is a new type of brewing equipment, which has the characteristics of high speed and high efficiency. It can automatically add water, bend pipes, unload materials and mix evenly, with ideal cooling effect. Bending device is one of the most important devices in stubble cooler. The elbow device is located at the bottom of the stubble cooler to collect the materials leaked from the discharge port, so as to save materials and avoid waste.
涼茬機本身就有很好的優勢
The stubble cooler itself has good advantages
冷茬機是在將殘茬冷卻攪拌后，加入酒曲進行混合的設備。工作時間短，非常節省資源，自動上下料，減輕工人勞動強度，杜絕浪費糧食的現象。與顆粒接觸的部分均采用不銹鋼制造。此外，機器在使用時，輸送、攪拌、下降均采用變頻調速。
The stubble cooler is a device that adds distiller's yeast for mixing after cooling and stirring the stubble. The working time is short, which can save resources. It can automatically load and unload materials, reduce the labor intensity of workers, and eliminate the phenomenon of wasting food. The parts in contact with particles are made of high-quality stainless steel. In addition, when the machine is in use, frequency conversion speed regulation is adopted for conveying, mixing and lowering.
使用時，酒茬在傳送帶上通過，風機邊粉碎攪拌邊工作，溫度迅速降溫，冷卻后的酒茬與進料裝置中的酒曲自動混合。本實用新型的全自動涼茬機提高了冷卻效果，降低了電耗，了現有設備的自積堵現象，實現了殘茬和酒曲的自動混合。
When in use, the wine stubble passes through the conveyor belt, the fan works while crushing and mixing, the temperature drops rapidly, and the cooled wine stubble is automatically mixed with the starter in the feeding device. The full-automatic stubble cooler of the utility model improves the cooling effect, reduces the power consumption, solves the self accumulation and blocking phenomenon of the existing equipment, and realizes the automatic mixing of stubble and koji.
在啟動自動冷茬機前，要檢查機器的電機是否正常，然后再啟動設備。檢查時應同時用吹風機吹掃電機內的灰塵等臟物，并測量接線是否合格。如果發現電機有機械損壞或火花，應立即進行必要的處理。
Before starting the automatic stubble cooler, first check whether the motor of the machine is normal, and then start the equipment. During the inspection, the blower shall be used to purge the dust and other dirt in the motor and measure whether the wiring is qualified. If mechanical damage or sparks are found in the motor, necessary treatment shall be carried out immediately.
涼茬機是如何達到節材目的的：
How does the stubble cooler achieve the purpose of material saving:
1、在冷茬機料斗進料口正下方、冷茬機底部傳動鏈上方設置弧形筐；
1. An arc-shaped basket is arranged directly below the hopper feed port of the stubble cooler and above the transmission chain at the bottom of the stubble cooler;
2、連接籃的兩端分別固定在冷茬機支架的橫梁上；
2. Both ends of the connecting basket are respectively fixed on the cross beam of the stubble cooler support;
3、彎籃為一端抬起的折疊護板；
3. The bent basket is a folding guard board raised at one end;
4、折疊護板的凸起端設有調節螺栓，用于調節彎籃在橫梁上的折疊高度；
4. The convex end of the folding guard plate is provided with an adjusting bolt for adjusting the folding height of the bending basket on the beam;
5、弧形料斗出料口漏出物料的收集結構由弧形轉籃構成。
5. The collecting structure of materials leaked from the discharge port of the arc hopper is composed of an arc-shaped rotating basket.
6、本實用新型可有效收集和再利用泄漏物，從而節省材料。
6. The utility model can effectively collect and reuse the leakage, thereby saving materials.
以上就是問題解答的相關內容了，希望能夠幫助到大家，如對這一問題還存在任何疑問，都歡迎關注我們網站
http://www.xgbmw.cn并咨詢我們的工作人員，將竭誠為您服務。
The above is the relevant content of the question answer. I hope it can help you. If you still have any questions about this problem, you are welcome to follow our website http://www.xgbmw.cn And consult our staff, will serve you wholeheartedly.
